IGM-Pilot Handrail Light

Gray
Xóa
Tùy chọn

  • Type

    Round Symmetrical

  • Power

    1.5W (24V DC or 500mA)

  • Absolute Luminous Flux

    139lm (at 3000K)
    140lm (at 4000K)

  • Beam

    70° (W)

  • Handrail Size Suitability

    Ø38-45mm, Ø48-63mm

  • Handrail Wall Thickness

    1-2mm

  • Type

    Round Symmetrical

  • Power

    1.5W (24V DC or 500mA)

  • Absolute Luminous Flux

    119lm (at 3000K)
    122lm (at 4000K)

  • Beam

    70° Asymmetrical (W)

  • Handrail Size Suitability

    Ø38-45mm, Ø48-63mm

  • Handrail Wall Thickness

    1-2mm

  • Type

    Flat Symmetrical

  • Power

    1.5W (24V DC or 500mA)

  • Absolute Luminous Flux

    125lm (at 3000K)
    127lm (at 4000K)

  • Beam

    70° (W)

  • Handrail Size Suitability

    ≥50x50mm

  • Handrail Wall Thickness

    0.8-3mm

  • Type

    Flat Asymmetrical

  • Power

    1.5W (24V DC or 500mA)

  • Absolute Luminous Flux

    107lm (at 3000K)
    110lm (at 4000K)

  • Beam

    70° Asymmetrical (W)

  • Handrail Size Suitability

    ≥50x50mm

  • Handrail Wall Thickness

    0.8-3mm

Thông số kỹ thuật

Finish

Anodised Aluminium
316L Stainless Steel

Material

Anodised Aluminium
316 Stainless Steel

IP Rating

IP66/67

IK Rating

IK10

Wiring

Wired in Parallel
Wired in Series

Warranty

5 Years

Colour Temp

2700K
3000K
4000K

CRI

80+ (R9: >0)

Efficacy

Up to 93lm/W

Colour Deviation

SDCM≤3

Lifetime

>60,000h L80B10

Mô tả sản phẩm

Enhance aesthetics and visibility with the Pilot Handrail Series, which offers a slimline, unobtrusive design that is the perfect solution for any round or square handrail configuration. This continuous flow of light contributes to both safety and ambience, delivering the most functional illumination. With an IP rating of 67, this luminaire offers protection against dust and the ingress of water. The Pilot can also be customised in size, finish and CCT for ultimate flexibility.
